Two Piece Ball and Sleeve Plunger

Two Piece Ball and Sleeve Plunger

The Two Piece Ball and Sleeve Plunger requires special training and understanding to operate effectively. It is typically used for high cycle counts and handling large fluid volumes. It consists of two separate parts.

The Sleeve

The main body hollowed throughout the center.

The Ball

A matching ball that mates with a seating surface on the bottom of the sleeve.

Improper cycle timing can damage the bottom hole spring, so proper design and application are crucial. The Ball and Sleeve Plunger requires a trip rod assembly in the lubricator to dislodge the ball from the sleeve and to prevent the sleeve from dropping until the well is cycled closed for a minimal time.

Falls against flow and a lubricator trip rod is required.
